Save $4,500.00!

Jensen Touchscreen Double Din Deck DVD/MP3/WMA Receiver

Original price was: $8,500.00.Current price is: $4,000.00.

Brand Name: Jensen

Product Model: VM9020TS



For product availability, please contact us first.

  • Check Mark Prices are in Trinidad and Tobago Dollars TTD
  • Check Mark In-Store Purchase ONLY!
  • Check Mark To get in touch with us, visit our Contact/ Location Page
  • Check Mark For ALL of our items, we provide a Layaway Plan
Our Payment Options
  • linx logo payment
  • TTD dollar notes

Description

Jensen Touchscreen Double Din Deck for Vehicles VM9020TS Multimedia DVD/MP3/WMA Receiver

This Jensen Double Din Deck Touchscreen is designed to fit into a 2.0 DIN dashboard opening with 280 watts, found in many imported cars. The unit has threaded holes in the chassis side panels, which may be used with the original factory mounting brackets for the majority of Toyota, Nissan, Mitsubishi, Isuzu, Hyundai, and Honda vehicles to mount the radio to the dashboard. Please consult with your local car stereo specialty shop for assistance on this type of installation.

What is a double din deck?

double DIN deck refers to a type of car stereo or head unit that conforms to the standardized size of 4 inches (100 mm) in height and 7 inches (180 mm) in width. The term “DIN” is used to establish these dimensions to ensure compatibility across vehicles and aftermarket stereos. Double DIN stereos are typically found in modern vehicles but can also replace existing double DIN units in older cars. However, if your vehicle originally has a single DIN slot, you would need an adapter or mounting kit to install a double DIN unit.

In summary, a double DIN deck is a versatile and feature-rich option for upgrading your car’s audio and infotainment system, especially if you prioritize functionality and display size.



IMPORTANT: Incorrect wiring connections can damage the unit. Follow wiring instructions carefully, or have the installation handled by an experienced technician.

Additional information

Power Output

18 Watts RMS x 4 channels into 4-ohms @ < 1% THD+N

Signal to Noise Ratio

70dBA below reference. (Reference: 1 watt, 4-ohms)

Dynamic Power

88 watts into 4-ohms, all channels driven

Reference Supply Voltage

14.4 VDC

Compatible Formats

DVD-R, DVD-RW, DVD+R, DVD+RW, CD-R, CD-RW, CD-DA, MP3, WMA, HDCD, SVCD, VCD, MPEG, JPEG, MP3/WMA files burned onto a DVD+R/W or DVD-R/W and Kodak Picture CD

Channel Separation

> 60dB @1kHz

D/A Converters

6-Channel high performance 24-bit, 192kHz, multi-bit Sigma Delta modulation. DAC supports sample rates from 8~192kHz

Electronic Skip Protection (ESP)

16Mbit high-speed flash memory

Video Format

NTSC, PAL (auto-detection)

Video Output

1Vp-p (75-ohms), buffered

Video Input

1Vp-p (75-Ohms)

FM Tuner Tuning Range

87.5MHz – 107.9MHz

Mono Sensitivity (-30dB)

9dBf

Quieting Sensitivity (-50dB)

15dBf

Alternate Channel Selectivity

70dB

Signal to Noise Ratio @ 1kHz

58dB

Image Rejection

80dB

Stereo Separation @ 1kHz

30dB

Frequency Response

30Hz – 15kHz

Monitor Screen Size

6.5" (Measured Diagonally), 16:9 Widescreen – 6.1" (155mm) W x 3.51" (89.2mm) H

Monitor Screen Type

TFT Liquid Crystal Display (LCD), Active Matrix, Anti-glare Screen

Monitor Brightness

400 cd/m2

Monitor Contrast Ratio

350

Monitor Response Time

15mS rise time, 25mS fall time

Monitor Resolution

280, 800 sub pixels, 1200 (W) x 234 (H)

Monitor Viewing Angle

65 degrees left or Right, 40 degree up, 65 degrees down

Auxiliary Input Impedance

10k

Power Supply

11 to 16VDC, negative ground

Fuse

10-amp, mini ATM type

Memory Slot

SD Card Slot

Double-DIN chassis dimensions

7" x 7" x 4" (178mm x 178mm x 100mm)

Features

Last memory for optical disc, Multi-language, Parental Lock – uses a password and disc rating setup to prevent authorized user access from display content. Two remote controls – a full function front remote control and a limited function Kid-Zone remote control for back seat operation.
