Audiopipe Graphic Equalizer Dual Channel 15 Bands for Home or DJ

$2,800.00

For product availability, please contact us first.

  • Check Mark Prices are in Trinidad and Tobago Dollars TTD
  • Check Mark In-Store Purchase ONLY!
  • Check Mark To get in touch with us, visit our Contact/ Location Page
  • Check Mark For ALL of our items, we provide a Layaway Plan
Our Payment Options
  • linx logo payment
  • TTD dollar notes

Audiopipe Dual Channel Graphic Equalizer for Home or DJ, 15 Bands, AEQ-215XL

Audiopipe AEQ-215XL Graphic Equalizer 15-Band Stereo EQ for Home Audio or DJ Setup, Dual Channel Professional Black DJ Equalizer. This DJ or home stereo graphic equalizer has noise reduction and can be rack mounted.

Features:

  • Dual 15-band, 2/3-octave Constant Q frequency bands
  • Switchable boost/cut ranges of ±6 or ±12 dB
  • 12 dB per octave 50 Hz low-cut filter
  • Front-panel bypass switch
  • ±12 dB input gain range
  • 4-segment LED ladder for monitoring output levels
  • XLR and TRS inputs and outputs
  • Internal Toroidal Transformer
  • Frequency Response of 10 Hz to >50 kHz
  • Dynamic range greater than 108 dB

Specifications:

  • Input:
    Connectors: 1/4″ TRS, female XLR (pin 2 hot)
    Type: Electronically balanced/unbalanced, RF filtered
    Impedance: Balanced 40 Kohms
    Max Input Level: +21 dB at 1 kHz

  • Output:
    Connectors: 1/4″ TRS, male XLR (pin 2 hot)
    Type: Impedence-balanced/unbalanced, RF filtered
    Impedance: Balanced 100 ohms, unbalanced 50 ohms
    Max Output Level:
    > + 21dBu balanced/unbalanced into 2k or greater
    > +18dBm balanced/unbalanced (into 6000)

  • Function Switches
    EQ Bypass: Bypass the graphic equalizer section in the signal path
    Low Cut: Activates the 50Hz 12 dB/octave high-pass filter
    Range: Selects either ± 6 dB or ± 12 dB slider
    Boost/cut range



  • PRECISE EQUALIZER: This professional-grade equalizer features dual 15-band, 2/3-octave constant Q frequency bands, allowing you to adjust the sound quality of your music or recordings precisely
  • TRS/XLR INPUTS AND OUTPUTS: Featuring ¼” TRS, (female/male) XLR inputs and outputs, this equalizer offers professional-grade connectivity for a seamless audio experience
  • ENHANCED TRANSFORMER: This equalizer boasts an incredible internal toroidal transformer, enhancing the overall sound quality and providing a truly immersive listening experience
  • LED MONITOR: 4-segment LED ladders are included to monitor and adjust output levels accurately, providing precise control for optimal audio performance
  • FUNCTION SWITCHES: This equalizer features EQ bypass function switches that allow you to temporarily bypass the graphic equalizer section in the signal path, providing a seamless signal flow without altering the sound quality
  • POWER SUPPLY: This graphic equalizer is designed with a power supply voltage of 120V AC / 60Hz and a power consumption of 12W. The unit also has a mains connection for easy and secure use through an IEC receptacle

With its dual-channel 15-band, 2/3-octave constant Q frequency bands, this excellent equalizer allows you to precisely adjust your recordings or music. Professional-grade connectivity is at your fingertips for an unmatched audio experience, thanks to TRS and XLR inputs and outputs. A genuinely immersive listening experience is produced by the internal toroidal transformer, which improves the sound quality. This Audiopipe equalizer, which uses only 12W of power and is powered by 120V AC/60Hz, is safe and simple to use. It connects to the mains via an IEC outlet.

Brand Name

Model

AEQ-215XL

Power Consumption

12W

Number of Channels

2 Channels

Number of Band

15 Bands

Mains Connection

IEC receptacle

Operating Voltage

120V AC 60 HZ

SIZE (H x W x D)

44.5 x 483 x 152mm (1.75” x 19” x 6”)

WEIGHT

2.1 kg (4.7 lbs.)
